AW-540BL

The Windows interface and the intelligent software are easy to operate and easy to learn.
Our self-developed waveform control circuit is ahead of the industry in terms of accuracy and efficiency for processing large tapers and thicknesses.
The machine is made of high rigid castings with one-piece structure, heat-treated, high-temperature tempered and stress-removing procedures, and the X.Y axis uses PMI linear rails and ball screws to ensure long-lasting mechanical positioning accuracy.
An intelligent database is available for customers to select for different workpiece cutting needs, or to program their own processing parameters to access.
Multiple cutting parameters, one setting, fully intelligent control.
The new three-layer filtered water tank extends the service life of the working fluid, improves the cleanliness of the working fluid, enhances the performance of slag removal and improves efficiency, and adopts a new type of environmentally friendly cooling fluid, which fully complies with environmental protection regulations.
Suitable for machining demanding precision, high toughness . Difficult to machine conductive metal molds, complex metal parts and templates.
It can process flat, beveled up and down, and shaped surface, which greatly enhances the processing range of wire-cutting machine powerful network function and realize remote control.

Item	Unit	AW-540BL
Worktable size	mm	785×500
Table travel	mm	400×500
Max. weight of processed parts	kgs	400
Max. thickness for straight line processing	mm	500
Max. processing speed	mm2 / min	120-160
Best surface roughness	μm	≤1.5
WORKPIECE ACCURANCY	mm	≤0.015(mm)
CUTTING TAPER	mm	±30° / 100( 度/mm )μ
Electrode molybdenum diameter	mm	0.18~0.20
Max. processing power	A	6
INPUT VOLTAGE	KVA	3
Cutting fluid capacity	L	56
Machine Net Weight	kgs	2000
Machine dimensions	mm	150010001850
